ステンレス形鋼 角パイプ

角パイプ 正方形 SUS304

HL=HL ④=#400 未=未研磨

サイズ 肉厚 長さ 研磨 角R(外R) 重量 断面積 断面二次モーメント 断面係数 断面二次半径
t mm HL 400 未研 mm kg/m cm2 Ixcm4 Iycm4 Zxcm3 Zycm4 ixcm iycm
7 × 7 1.0 4,000 HL 1.0 0.184 0.231 0.014 0.040 0.245
9 × 9 1.0 4,000 HL 1.0 0.247 0.311 0.033 0.074 0.326
10 × 10 1.0 4,000 HL 1.0 0.279 0.351 0.047 0.094 0.367
1.2 4,000 HL 1.2 0.325 0.410 0.053 0.106 0.359
12 × 12 1.0 4,000 HL 1.0 0.342 0.431 0.087 0.144 0.448
1.2 4,000 HL 1.2 0.401 0.506 0.098 0.163 0.440
13 × 13 1.0 4,000 HL 1.0 0.374 0.471 0.113 0.173 0.489
1.2 4,000 HL 1.2 0.439 0.554 0.128 0.197 0.481
14 × 14 1.0 4,000 HL 1.0 0.406 0.551 0.143 0.205 0.530
1.2 4,000 HL 1.2 0.477 0.602 0.164 0.234 0.521
16 × 16 1.0 5,000 HL 1.0 0.469 0.591 0.221 0.276 0.661
1.2 5,000 HL 1.2 0.554 0.698 0.254 0.317 0.603
1.5 5,000 HL 2.25 0.675 0.851 0.297 0.391 0.591
6,000 HL
19 × 19 1.0 5,000 HL 1.0 0.564 0.711 0.383 0.403 0.733
1.2 5,000 HL 1.2 0.668 0.842 0.443 0.466 0.725
1.5 5,000 HL 2.25 0.187 1.031 0.524 0.551 0.713
6,000 HL
2.0 5,000 HL 3.0 1.05 1.326 0.636 0.669 0.693
20 × 20 1.2 5,000 HL 1.2 0.706 0.890 0.522 0.522 0.766
1.5 5,000 HL 2.25 0.865 1.091 0.619 0.619 0.754
21 × 21 1.0 5,000 HL 1.0 0.628 0.791 0.526 0.501 0.815
1.2 5,000 HL 1.2 0.744 0.938 0.610 0.581 0.807
1.5 5,000 HL 2.25 0.913 1.151 0.726 0.691 0.794
22 × 22 1.0 5,000 HL 1.0 0.659 0.831 0.609 0.553 0.856
1.2 5,000 HL 1.2 0.782 0.986 0.708 0.644 0.847
1.5 5,000 HL 2.25 0.960 1.211 0.844 0.767 0.835
24 × 24 1.0 5,000 HL 1.0 0.723 0.911 0.801 0.667 0.937
1.2 5,000 HL 1.2 0.858 1.082 0.934 0.778 0.929
1.5 5,000 HL 2.25 1.06 1.331 1.118 0.932 0.917
25 × 25 1.2 5,000 HL 1.2 0.896 1.130 1.063 0.850 0.970
1.5 5,000 HL 2.25 1.10 1.391 1.274 1.020 0.957
6,000 HL
25.4 × 25.4 1.2 5,000 HL 1.2 0.911 1.149 1.117 0.880 0.986
1.5 5,000 2.25 1.12 1.415 1.341 1.056 0.974
28.6 × 28.6 1.2 5,000 1.2 1.03 1.303 1.624 1.136 1.117
1.5 5,000 HL 2.25 1.27 1.607 1.959 1.370 1.104
30 × 30 1.2 5,000 HL 1.2 1.09 1.370 1.888 1.258 1.174
1.5 5,000 HL 2.25 1.34 1.691 2.280 1.520 1.161
6,000 HL
2.0 5,000 HL 3.0 1.75 2.205 2.869 1.912 1.140
32 × 32 1.2 5,000 HL 1.2 1.16 1.466 2.310 1.444 1.255
1.5 5,000 HL 2.25 1.44 1.811 2.797 1.748 1.243
6,000 HL
2.0 5,000 HL 3.0 1.88 2.366 3.533 2.208 1.222
35 × 35 1.2 5,000 HL 1.2 1.28 1.610 3.056 1.746 1.378
1.8 5,000 HL 2.25 1.58 1.991 3.710 2.120 1.365
38.5 × 38.5 1.2 5,000 HL 1.2 1.41 1.778 4.111 2.136 1.521
1.5 5,000 HL 2.25 1.75 2.201 5.005 2.600 1.508
2.0 5,000 HL 3.0 2.29 2.886 6.382 3.315 1.487
40 × 40 1.5 5,000 HL 2.25 1.82 2.291 5.641 2.820 1.569
6,000 HL
2.0 5,000 HL 3.0 2.38 3.006 7.205 3.603 1.548
6,000 HL
41 × 41 1.2 5,000 HL 1.2 1.51 1.898 4.998 2.438 1.623
1.5 5,000 HL 2.25 1.86 2.351 6.093 2.972 1.610
6,000 HL
2.0 5,000 HL 3.0 2.45 3.086 7.792 3.801 1.589
46 × 46 1.5 5,000 HL 2.25 2.10 2.651 8.723 3.793 1.814
2.0 5,000 HL 3.0 2.76 3.486 11.207 4.872 1.793
50 × 50 1.5 5,000 HL 2.25 2.29 2.891 11.302 4.521 1.977
6,000 HL
2.0 5,000 HL 3.0 3.02 3.806 14.564 5.826 1.956
6,000 HL
3.0 5,000 HL 6.0 4.41 5.563 20.392 8.157 1.915
6,000 HL
60 × 60 1.5 5,000 HL 2.25 2.77 3.491 19.863 6.621 2.385
6,000 HL
2.0 5,000 HL 3.0 3.65 4.606 25.746 8.582 2.364
6,000 HL
3.0 5,000 HL 6.0 5.36 6.763 36.476 12.159 2.322
75 × 75 2.0 5,000 HL 3.0 4.60 5.806 51.436 13.716 2.977
6,000 HL
3.0 5,000 HL 6.0 6.79 8.563 73.731 19.662 2.934
100 × 100 2.0 5,000 HL 3.0 6.19 7.806 124.701 24.940 3.997
6,000 HL
3.0 5,000 HL 6.0 9.17 11.563 180.829 36.166 3.955
画像を入れる。

角パイプ 長方形 SUS304

HL=HL ④=#400 未=未研磨

サイズ 肉厚 長さ 研磨 角R(外R) 重量 断面積 断面二次モーメント 断面係数 断面二次半径
t mm HL 400 未研 mm kg/m cm2 Ixcm4 Iycm4 Zxcm3 Zycm4 ixcm iycm
19 × 10 1.0 4,000 HL 1.0 0.421 0.531 0.084 0.237 0.168 0.249 0.397 0.667
1.2 4,000 HL 1.2 0.496 0.626 0.095 0.271 0.190 0.286 0.389 0.658
22 × 12 1.0 5,000 HL 1.0 0.501 0.631 0.147 0.388 0.245 0.353 0.483 0.784
1.2 5,000 HL 1.2 0.592 0.746 0.168 0.488 0.280 0.407 0.475 0.775
1.5 5,000 HL 2.25 0.722 0.911 0.195 0.528 0.325 0.480 0.463 0.762
24 × 14 1.0 5,000 HL 1.0 0.564 0.711 0.228 0.536 0.326 0.447 0.566 0.868
1.2 5,000 HL 1.2 0.668 0.842 0.262 0.622 0.375 0.518 0.558 0.859
1.5 5,000 HL 2.25 0.817 1.031 0.307 0.738 0.439 0.615 0.546 0.846
25 × 12 1.2 5,000 HL 1.2 0.649 0.818 0.189 0.621 0.316 0.496 0.481 0.871
1.5 5,000 HL 2.25 0.794 1.001 0.220 0.735 0.367 0.588 0.469 0.857
30 × 20 1.2 5,000 HL 1.2 0.896 1.130 0.734 1.390 0.734 0.926 0.806 1.109
1.5 5,000 HL 2.25 1.10 1.391 0.877 1.670 0.877 1.113 0.794 1.096
6,000 HL
30 × 25 1.2 5,000 1.2 0.991 1.250 1.223 1.639 0.986 1.092 0.993 1.145
1.5 5,000 HL 2.25 1.22 1.541 1.482 1.975 1.185 1.317 0.981 1.132
32 × 16 1.0 5,000 HL 1.2 0.723 0.911 0.401 1.198 0.501 0.749 0.663 1.146
1.2 5,000 HL 1.2 0.858 1.082 0.464 1.399 0.580 0.875 0.655 1.137
1.5 5,000 HL 2.25 1.96 1.331 0.550 1.680 0.687 1.050 0.643 1.123
6,000 HL
40 × 18 1.0 5,000 HL 1.0 0.881 1.111 0.640 2.250 0.711 1.125 0.759 1.423
1.2 5,000 HL 1.2 1.05 1.322 0.745 2.641 0.828 1.321 0.751 1.413
1.5 5,000 HL 2.25 1.29 1.631 0.889 3.194 0.988 1.597 0.738 1.399
40 × 20 1.2 5,000 HL 1.2 1.09 1.370 0.947 2.820 0.947 1.410 0.831 1.440
1.5 5,000 HL 2.25 1.34 1.691 1.134 3.416 1.134 1.708 0.819 1.421
6,000 HL
2.0 5,000 HL 3.0 1.75 2.206 1.406 4.315 1.406 2.157 0.799 1.399
40 × 25 1.2 5,000 HL 1.2 1.18 1.490 1.573 3.274 1.258 1.638 1.027 1.482
1.5 5,000 HL 2.25 1.46 1.841 1.897 3.972 1.517 1.986 1.015 1.469
6,000 HL
2.0 5,000 HL 3.0 1.91 2.406 2.380 5.037 1.904 2.519 0.995 1.447
50 × 20 1.2 5,000 HL 1.2 1.28 1.610 1.159 4.940 1.159 1.976 0.848 1.752
1.5 5,000 HL 2.25 1.58 1.991 1.391 6.008 1.391 2.403 0.836 1.737
6,000 HL
2.0 5,000 HL 3.0 2.07 2.606 1.732 7.648 1.732 3.059 0.815 1.713
50 × 25 1.5 5,000 HL 2.25 1.70 2.141 2.311 6.890 1.849 2.756 1.039 1.794
6,000 HL
2.0 5,000 HL 3.0 2.22 2.806 2.910 8.801 2.328 3.520 1.018 1.771
50 × 30 1.5 5,000 HL 2.25 1.82 2.291 3.499 7.772 2.333 3.109 1.236 1.842
6,000 HL
2.0 5,000 HL 3.0 2.38 3.006 4.440 9.953 2.960 3.981 1.215 1.820
51 × 26 1.2 5,000 HL 1.2 2.41 1.778 2.126 6.087 1.636 2.387 1.094 1.850
1.5 5,000 HL 2.25 1.75 2.201 2.572 7.422 1.978 2.911 1.081 1.836
2.0 5,000 HL 3.0 2.29 2.886 3.245 9.491 2.496 3.722 1.060 1.814
60 × 25 1.5 5,000 HL 2.25 1.94 2.441 2.726 10.878 2.181 3.626 1.057 2.111
60 × 30 1.5 5,000 HL 2.25 2.05 2.591 4.109 12.162 2.739 4.054 1.259 2.167
6,000 HL
2.0 5,000 HL 3.0 2.70 3.406 5.225 15.650 3.483 5.217 1.239 2.144
6,000 HL
60 × 40 1.5 5,000 HL 2.25 2.29 2.891 7.865 14.729 3.933 4.910 1.649 2.257
2.0 5,000 HL 3.0 3.02 3.806 10.096 19.015 5.048 6.338 1.629 2.235
61 × 32 1.5 5,000 HL 2.25 2.13 2.681 4.822 13.200 3.014 4.328 1.341 2.219
6,000 HL
2.0 5,000 HL 3.0 2.80 3.526 6.147 17.006 3.842 5.576 1.320 2.196
65 × 18 1.2 5,000 HL 1.2 1.52 1.992 1.169 9.174 1.299 2.823 0.780 2.185
1.5 5,000 HL 2.25 1.89 2.381 1.401 11.203 1.556 3.447 0.767 2.169
70 × 25 1.5 5,000 HL 2.25 2.17 2.741 3.141 16.086 2.513 4.596 1.071 2.423
2.0 5,000 3.0 2.86 3.606 3.971 20.737 3.177 5.925 1.049 2.398
70 × 30 1.5 5,000 HL 2.25 2.29 2.891 4.719 17.846 3.146 5.099 1.278 2.485
2.0 5,000 HL 3.0 3.02 3.806 6.010 23.049 4.007 6.585 1.257 2.461
70 × 45 1.5 5,000 HL 2.25 2.77 3.491 12.405 27.300 5.514 7.280 1.885 2.797
6,000 HL
2.0 5,000 HL 3.0 3.65 4.606 16.008 35.445 7.115 9.452 1.864 2.774
6,000 HL
3.0 5,000 HL 6.0 5.36 6.763 22.476 50.390 9.989 13.437 1.823 2.730
80 × 40 1.5 5,000 HL 2.25 2.77 3.491 10.090 29.598 5.045 7.400 1.700 2.912
6,000 HL
2.0 5,000 HL 3.0 3.65 4.606 12.987 38.437 6.493 9.609 1.679 2.889
6,000 HL
3.0 5,000 HL 6.0 5.36 6.763 18.140 54.658 9.070 13.664 1.638 2.843
90 × 30 1.5 5,000 HL 2.25 2.77 3.491 5.938 33.702 3.959 7.489 1.304 3.107
2.0 5,000 HL 3.0 3.65 4.606 7.581 43.756 5.054 9.724 1.283 3.082
3.0 5,000 HL 6.0 5.36 6.763 10.414 62.191 6.943 13.820 1.241 3.032
90 × 50 1.5 5,000 HL 2.25 3.24 4.091 18.361 45.451 7.344 10.100 2.119 3.333
2.0 5,000 HL 3.0 4.29 5.406 23.786 59.247 9.514 13.166 2.098 3.311
100 × 40 2.0 5,000 HL 3.0 4.29 5.406 15.877 67.069 7.939 13.414 1.714 3.522
3.0 5,000 HL 6.0 6.31 7.963 22.256 96.121 11.128 19.224 1.672 3.474
100 × 40 2.0 5,000 HL 3.0 4.60 5.806 26.091 76.675 10.436 15.335 2.120 3.634
6,000 HL
2.0 5,000 HL 6.0 6.79 8.563 36.982 110.239 14.793 22.048 2.078 3.588
6,000 HL
120 × 60 2.0 5,000 HL 3.0 5.56 7.006 45.938 134.364 15.313 22.394 2.561 4.379
3.0 5,000 HL 6.0 8.22 10.363 65.744 194.585 21.915 32.431 2.519 4.333
120 × 75 2.0 5,000 HL 3.0 6.19 7.806 78.088 171.207 20.823 27.393 3.163 4.688
3.0 5,000 HL 6.0 9.17 11.563 112.634 248.783 30.036 39.805 3.121 4.639
150 × 50 2.0 5,000 HL 3.0 6.19 7.806 37.617 211.356 15.047 28.181 2.195 5.204
3.0 5,000 6.0 9.17 11.563 53.572 307.121 21.429 40.949 2.152 5.154
角パイプ 長方形 SUS430
サイズ 長さ\肉厚 1.0 2.0
32 × 16 5,000 HL HL
外径公差基準表
辺の長さ 30㎜未満 ±0.25㎜
30mm以上50㎜未満 ±0.30㎜
50mm以上 ±0.6%
厚さ 1.25㎜未満 ±0.15mm
1.25㎜以上2.0㎜未満 ±0.20mm
2.0㎜以上 ±10%
長さ 4000㎜~6000㎜ +50mm、-0㎜
曲がり 全長に対し 0.3%以下
角R(外R)の
寸法
肉厚t=1.5mm未満 R=1.0Xt(肉厚)以下
肉厚t=1.5mm以上2.1㎜未満 R=1.5Xt(肉厚)以下
肉厚t=2.1mm以上 R=2.0Xt(肉厚)以下
